3轴激光测径仪适用于监控高速生产线上的多种工艺过程，包括拉伸、
涂层护套和着色等。它能够精准检测并表征一系列细微缺陷，如肿
块颈缩、水泡、气泡、粗节、划痕、粒子污染、涂层脱落及挫伤等
| 产品型号(Product model) | LN-2004 | LN-3005 | LN-3020 |
| 适用线径(Applicable Diameter) | 0.02-1mm | 0.05-5mm | 0.1-18mm |
| 检测轴数(Number of axes) | 2 axes | 3 axes | |
| 配置组成(Configuration) | Detection head + controller | ||
| 检测方式(Detection Method) | Non-contact continuous detection with infrared light curtain | ||
| 凹凸设定范围(Lump and Neck Range) | 0.002－0.999mm | ||
| 检测灵敏度（Accuracy) | 设定值的±1%(+1% of set value) | ||
| 线速度(Line Speed) | 5m/min~1500m/min | ||
| 报警输出(Alarm output) | 24V,1A(触点负载)(contact load) | ||
| VO 接口 (IV/O Interface) | 脉冲输入、数字量输入(Pulse input,digital quantity input) | ||
| 环境温度（Temperture) | 0 至 +50℃C (32 至 122° F)(0 to +50° C(32 to 122° F)) | ||
| 环境湿度(Humidity) | 35%至85% RH,无凝结(35% to 85% RH, non-condensing) | ||
| 供电电源(Power supply) | AC220V | ||
| 尺寸大小(Probe size) | 123x123x30(mm) | 152x156x40(mm) | 165x181x47(mm) |
